The instruction of remote control

Lancy He www.smart-home-security.cn 2016-07-14 16:10:24
In our daily life, we always can see many remote control, and usually it can be used with accesw control system. The main product of our company is access control system, so we can supply many types of remote control. Below is information about our remote control:

Main technical indicators:

1. Operating voltage: 12VDC (other voltages can be customized)

2. Quiescent operating current: 6mA

3. Working temperature: -30 ~ +70 degrees

4. Receiver sensitivity:-103dBm

5. Operating frequency: 315MHz, 433MHz special frequency can be customized

6. Controller Size: 68.0mmX48.0mmX19.0mm

Output Mode: This model has three output modes: signal interlocking, signal of non-lock, the signal delay 2 seconds of non-lock (delay time can be customized)

1. Signal interlocking: 1 and 2 connections

A key by remote control, the corresponding relay A suction to keep the merger; press B button, A disconnect relay, and B keys corresponding to relay the merger to maintain suction. Do the same work cycle.

2. Signal Non-lock: 1 and 2 and 3 are not connected

A key by remote control, and A keys corresponding to the relay pull-in, release immediately after the relay off; press the B key, with the B button corresponding to the relay pull-in, release immediately after the break.

3. Signal Delay 2 seconds of non-lock: 2 and 3 to connect

A key by remote control, and A keys corresponding to the merger delay relay suction disconnected after 2 seconds, press the remote control button B, and B keys corresponding to the merger delay relay suction disconnected after 2 seconds. (Delay time can be customized)

This offering relay output has LED work instructions, operation and intuitive, easy to use.

Wiring Diagram


Some pictures about our remote control:




If you are interested in our product, feel free to contact us!
