Home > Products > Access Control System > RF Card Access Control > IP43 waterproof RFID single do.....
IP43 waterproof RFID single door access control with keypad PY-668BIP43 waterproof RFID single door access control with keypad PY-668BIP43 waterproof RFID single door access control with keypad PY-668B

IP43 waterproof RFID single door access control with keypad PY-668B

  • Waterproof level: IP43
  • User capacity: 2000 and 10 universal password
  • This system supports multi-mode entry methods(“Card only”, “Card& Password” and “Card or Password”)
  • Material: plastic
  • Dimension:118*118*23mm

IP43 waterproof RFID single door access control with keypad PY-668B


Description:



This product is RFID access control system, which is currently one of the advanced access systems. It uses the latest central process unit (CPU) and memory chip of large capacity. There will be of no information loss even in case of power failure. It takes the latest HOMMARD technology, with strong power of three ways to open door: open by card read, open by card read adding with password, and open by password.



The perfect security functions let the users feel much more safe, which include door state monitoring, alarm output, safety mode, anti dismantling, RFID card and password. While its functions of opening button, close notification, door bell, to be connected with NO. and NC. locks bring more operating easiness to the users.





Technical Features:



No

Item

Specification

1

Power supply

DC: Voltage 12V current <0.1A

2

Max load

Alarm output: 100mA  Electrolock output: 3A

4

Weight

180g

5

Ambient temp.

-20 60

6

RH

20%—90%

7

Memory capacity

Information of 2000 user card, and 2000 passwords,Ten  Password

in common use

8

Universal Password

10 sets of universal password

9

Induction distance

8-13CM

10

Card type

EM or EM compatible card


Application: business organizations, offices, factories, residences and communities
