RFID waterproof metal access control with keypad PY-S100RFID waterproof metal access control with keypad PY-S100

RFID waterproof metal access control with keypad PY-S100

  • Waterproof degree:IP68
  • Working voltage:DC12V±10%
  • Static electricity:≤30mA
  • Alarm output:≤20A
  • User capacity: 2000 card user card, 2000 user password
  • Card read distance:5~8cm
RFID waterproof metal access control with keypad PY-S100



  •  Low power consumption: less than 30mA standby current
  •  Luminous keyboard: the night can also operate keyboard
  •  User capacity: support 2,000 users
  • Independent password: can use password which irrelevant with the card to open the door
  • User modification password: Users can revise the door password
  • Search speed: charge to open the door time less than 0.1 S.
  • Output short circuit protection: electric lock or alarm output circuit within 100 μS  when shut down automatically output
  • Wiegand output: With Wiegand output interface,Wg26 card number or Wg34 buttons output
  • Usable keyboard delete card number: After card is lost, usable keyboard delete cardThoroughly eliminate safety lapses
  • The demolition alarm: Illegal dismantling machine, built-in alarm sound buzzer
  • The bell button and interface: key and circuit segregation, external any the doorbell.


Technical parameters

  • Work VoltageDC9-28V
  • Static Current:≤30mA
  • Reading Range:3~8cm
  • Capacity: 2000 users
  • Ambient Temperature:-25°C~60°C
  • Ambient Humidity:10%~90%Electricity lock output:≤3A
  • Output short circuit protection time:100μS
